CAT 6030 Toggle Link
CAT 6030 Toggle Link - Image 2

CAT 6030 Toggle Link

Caterpillar 6030 Toggle Link | TriPower Front Shovel Linkage

OEM-spec Caterpillar 6030 toggle link engineered for 300-tonne class TriPower face shovels. Forged from high-tensile alloy steel with precision-machined pin bores and heavy-duty bronze bushings, designed to maintain mechanical roll-back leverage, increase breakout force, and sustain constant bucket angle during shovel loading.

Add part to quote
Category: Tag: Brand:

Description

OEM-Quality Caterpillar 6030 Toggle Link Assembly

Maintain maximum front-shovel digging efficiency and structural stability on your 300-tonne face shovel with a heavy-duty Caterpillar 6030 Toggle Link Assembly. Engineered specifically for Caterpillar 6030 FS (formerly Bucyrus RH120-E / O&K RH120) front shovels, this heavy-duty structural linkage component forms a vital part of Caterpillar’s unique TriPower kinematic system.

The toggle link works in tandem with the boom, stick, and bucket cylinders to generate parallel crowding forces and automatic constant bucket roll-back angle, delivering higher breakout forces while preventing power loss across high-wall mining faces.

Key Features & Benefits

  • Integral Component of TriPower Kinematics: Ensures automatic constant bucket guidance and increased roll-back torque without requiring extra hydraulic energy.

  • High-Tensile Cast/Forged Alloy Steel: Engineered to absorb extreme torsional twisting, high dynamic shock loads, and severe digging leverage forces.

  • Precision-Machined Pin Bores: Internal bores are line-bored to exacting tolerances to ensure perfect pin fitment, eliminating joint slop and premature bushing wear.

  • Heavy-Duty Self-Lubricating Bushings: Equipped with hardened steel or high-spec bronze bushings designed to retain grease under continuous heavy contact pressures.

  • Direct OEM Fit: Built to exact Caterpillar 6030 FS factory geometry for seamless installation into standard front attachment linkage pin joints.

Verified Technical Specifications

Parameter Specification
Compatible Machine Model Caterpillar 6030 FS (Front Shovel Configuration)
Legacy Cross-Reference Bucyrus RH120-E / O&K RH120 TriPower Shovel
Machine Weight Class ~287 – 300 tonnes (316 – 330 tons)
Kinematic Attachment System TriPower Kinematics (Parallel Crowding System)
Material Construction High-strength heat-treated forged/cast alloy steel
Bushing Type Heavy-duty grooved bronze/hardened steel bushings
Application Front Shovel Attachment Linkage Group
